| Structure |
Semi-metal structure |
Semi-metal structure |
Semi-metal structure |
| Print Area |
24mm*50mm |
24mm*50mm |
24mm*30mm |
| Resolution |
203dpi (8 dots/mm) |
203dpi (8 dots/mm) |
203dpi (8 dots/mm) |
| Print Speed |
40mm/s – 400mm/s |
40mm/s – 400mm/s |
40mm/s – 400mm/s |
| Real-time Clock Function |
STD |
STD |
STD |
| Sensor |
Ribbon tension sensor; thermal head position sensor; cover opening sensor; TPH over temperature sensor; ribbon break sensor |
Ribbon tension sensor; thermal head position sensor; cover opening sensor; TPH over temperature sensor; ribbon break sensor |
Ribbon tension sensor; thermal head position sensor; cover opening sensor; TPH over temperature sensor; ribbon break sensor |
| Packaging Sensor |
Electromagnetic induction, synchronizer (Continuous), photoelectric sensor, proximity sensor |
Electromagnetic induction, synchronizer (Continuous), photoelectric sensor, proximity sensor |
Electromagnetic induction, synchronizer (Continuous), photoelectric sensor, proximity sensor |
| Packaging Materials |
PVDCPET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, VMPET VMCPP and other films and composite films |
PVDCPET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, VMPET VMCPP and other films and composite films |
PVDCPET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, VMPET VMCPP and other films and composite films |
| Ribbon Length |
500 meters |
500 meters |
500 meters |
| Ribbon Type |
Wax/Resin, Resin |
Wax/Resin, Resin |
Wax/Resin, Resin |
| Interface |
USB Host Interface, Ethernet Interface |
USB Host Interface, Ethernet Interface |
USB Host Interface, Ethernet Interface |
| Air Supply |
0.35bar |
0.35bar |
0.35bar |
| Air Consumption |
0.01L |
0.01L |
0.01L |
| Power Supply |
Internal switching power supply module, AC 90V-264V, 47/63 Hz; 150VA |
Internal switching power supply module, AC 90V-264V, 47/63 Hz; 150VA |
Internal switching power supply module, AC 90V-264V, 47/63 Hz; 150VA |
| Software |
HPRT Format Designer |
HPRT Format Designer |
HPRT Format Designer |
